ACB (Air Circuit Breaker)
ACB (Air Circuit Breaker) is a high-capacity protective device used to protect electrical circuits, transformers, and distribution systems from overcurrent, short circuits, and electrical faults. Unlike MCCBs, ACBs are suitable for higher voltage and current ratings, making them ideal for industrial and commercial power distribution systems. They use air as the arc quenching medium and provide reliable switching, protection, and control for medium-voltage installations.
- Description
Description
Product Range / Variants
-
Fixed Type ACB
-
Withdrawable / Draw-Out Type ACB
-
Electrically Operated ACB
-
Manual ACB
-
High Interrupting Capacity (HIC) ACB
-
Microprocessor / Digital Controlled ACB
-
3-Pole / 4-Pole ACB
-
ACB with Trip Unit Options (Electronic / Thermal-Magnetic)
Key Features
-
High short-circuit breaking capacity
-
Reliable protection against overcurrent, overload, and short-circuits
-
Adjustable trip settings for precise protection
-
Air arc quenching for safe operation
-
Draw-out type for easy maintenance and inspection
-
Microprocessor-based monitoring (digital ACBs)
-
Compact design for panel integration
-
Compliance with IEC 60947-2 / IS standards
Technical Specifications
-
Rated Voltage: 415V – 1000V AC
-
Rated Current: 800A – 6300A (depending on model)
-
Breaking Capacity: 25kA – 100kA
-
Poles: 3P / 4P
-
Trip Mechanism: Thermal-Magnetic / Electronic / Microprocessor
-
Standards Compliance: IEC 60947-2 / IS 13947
-
Frequency: 50/60Hz
-
Mounting Type: Panel / Floor-mounted switchgear
-
Operating Temperature: -5°C to +40°C
Applications
-
Industrial power distribution systems
-
Commercial buildings and complexes
-
Large manufacturing plants
-
Transformers and generator protection
-
Switchgear and distribution panels
-
Renewable energy systems (solar, wind, hydro)
-
Critical infrastructure & emergency power systems
Benefits
-
Ensures high-capacity protection against electrical faults
-
Reduces downtime and prevents equipment damage
-
Adjustable and precise trip settings for various loads
-
Safe arc quenching with air medium
-
Easy maintenance and modular design
-
Reliable operation in industrial and commercial environments
-
Digital versions provide real-time monitoring and diagnostics
Material Grades / Build Options
-
Housing: High-strength thermoset or metal enclosure
-
Contacts: Copper / Silver alloy for high conductivity and durability
-
Arc Chute: Insulated metallic arc extinguishing chambers
-
Trip Unit: Thermal-magnetic / Electronic / Microprocessor-controlled
-
Terminals: Tin-plated or Silver-plated copper
-
Auxiliary Options: Shunt trip, undervoltage release, alarm contacts
